Fisher 64 Series High-Pressure Regulator
What is Fisher 64 Series High-Pressure Regulator
The Fisher 64 Series High-Pressure Regulator by Emerson/Fisher is a direct-acting regulator designed for precise pressure control of high-pressure gases such as propane, natural gas, or air. It effectively reduces high inlet pressure to a stable, controllable outlet pressure, making it ideal for industrial pipelines, commercial gas distribution systems, and downstream equipment supply. Constructed from durable aluminum and featuring 1/2" FNPT connections, this regulator ensures high flow capacity, reliability, and long-term performance in demanding applications.
Special versions, such as the 64SR (internal relief) and 64KB (corrosion-resistant for NH₃), provide tailored solutions for unique industrial needs.
Technical Specifications
|
Parameter |
Specification |
|
Capacity (Propane) |
3,600,000 BTU/HR (29.6 SCMH) |
|
Inlet Connection |
1/2 in. FNPT |
|
Outlet Connection |
1/2 in. FNPT |
|
Material |
Aluminum |
|
Maximum Allowable Inlet Pressure |
250 psig (17.2 bar) |
|
Maximum Emergency Outlet Pressure |
220 psig (15.2 bar) |
|
Outlet Pressure Setting |
20 psig (0.69 bar) |
|
Outlet Adjustment Range |
3 to 35 psig (0.21 to 1.0 bar) |
|
Temperature Capabilities |
-20° to 150°F (-29° to 66°C) |
|
Flow Coefficient (Cv) |
~35.6 |
|
Registration Type |
Internal |
|
Installation Orientation |
Horizontal or vertical |
|
Weight |
≈ 2.25 lb (≈ 1 kg) |
|
Applicable Media |
Propane, Natural Gas, Air (64KB suitable for NH₃) |
|
Certifications |
CSA/UL (if applicable) |
Applications of Fisher 64 series
- Industrial Gas Distribution Systems: High-flow primary pressure regulation for downstream equipment and secondary regulators.
- Commercial Gas Supply: Ensures stable pressure for burners, furnaces, and gas appliances.
- Process Equipment Protection: Reduces inlet pressure to safe, precise levels for sensitive equipment.
Special Versions
- 64SR Series (Internal Relief)
Feature: Built-in relief function protects downstream equipment from overpressure.
Application: Terminal pressure control for industrial furnaces or burners where safety relief is required.
- 64KB Series (Corrosion-Resistant)
Feature: PTFE diaphragm protects against corrosive gases such as anhydrous ammonia (NH₃).
Application: Chemical processing or storage systems requiring corrosion-resistant pressure regulation.
Company Advantages
- Genuine Emerson/Fisher Products: Assurance of original manufacturer quality and reliable performance.
- Expert Technical Support: Years of experience in industrial valves and regulators to provide optimal solutions.
- Fast Response & Service: Quick quotation, technical advice, and after-sales support to accelerate project execution.
- Global Supply Network: International distribution ensures timely product delivery and resource availability.
- 18-Month Warranty:All supplied products are backed by an 18-month warranty, providing added confidence and protection for your operations.
